Water valves are essential components used to control the flow and pressure of water in residential, commercial, and industrial piping systems. This category includes a wide range of valve types designed for various applications, such as ball valves, globe valves, check valves, and angle valves. Each type serves a specific purpose, whether it's allowing or stopping flow, preventing backflow, or regulating water pressure with precision. Manufactured using durable materials like brass, stainless steel, PVC, or cast iron, water valves offer reliable performance in both indoor and outdoor environments. They are corrosion-resistant, leak-proof, and designed for easy installation and maintenance, ensuring long-term operational efficiency. Many models come with ergonomic handles or levers for effortless manual control, while others support automation for use in advanced systems.
1 | Description | Raw Material |
2 | Body | Brass |
3 | Seal Ring | PTFE |
4 | Ball | Brass |
5 | Stem | Brass |
6 | O-Ring | NBR |
7 | Handle | lron |
G | DN | L | H | A |
1/2" | 13.5 | 47 | 60 | 95 |
3/4" | 19 | 55 | 75 | 102 |
1" | 23 | 64 | 94 | 113 |
1 1/4" | 29 | 77 | 106 | 130 |
1 1/2" | 35 | 87 | 112 | 146 |
2" | 44 | 98 | 126 | 174 |
2 1/2" | 62 | 125 | 169 | 210 |
3" | 69 | 135 | 180 | 265 |
4" | 79 | 146 | 195 | 265 |
1 | Description | Raw Material |
2 | Body | Brass |
3 | Seal Ring | PTFE |
4 | Ball | Brass |
5 | Stem | Brass |
6 | Packing Ring | PTFE |
7 | Lock Nut | Brass |
8 | Handle | lron |
G | DN | L | H | A |
1/2" | 13.5 | 51.5 | 60 | 95 |
3/4" | 19 | 59.5 | 75 | 102 |
1' | 23 | 69 | 94 | 113 |
Description | Raw Material | |
1 | Body | Brass |
2 | Seal Ring | PTFE |
3 | Ball | Brass |
4 | Stem | Brass |
5 | Packing Ring | PTFE |
6 | Lock Nut | Brass |
7 | Handle | lron |
8 | Lock Nut | Iron |
G | DN | L | H | A |
1/2" | 14 | 54 | 64 | 95 |
3/4" | 19 | 58 | 74 | 95 |
1" | 24 | 71 | 92 | 120 |
1 1/4" | 31 | 81 | 100 | 145 |
1 1/2" | 35 | 88 | 108 | 170 |
2" | 44 | 100 | 128 | 200 |
2 1/2" | 57 | 120 | 165 | 250 |
3" | 68 | 140 | 172 | 250 |
4" | 84 | 169 | 198 | 270 |
Description | Raw Material | |
1 | Body | Brass |
2 | Seal Ring | PTFE |
3 | Ball | Brass |
4 | Stem | Brass |
5 | 0-Ring | NBR |
6 | Handle | lron |
7 | Lock Nut | Iron |
G | DN | L | H | A |
1/2” | 12 | 47 | 53 | 85 |
3/4" | 15 | 50 | 56.5 | 85 |
1" | 19 | 59 | 72 | 110 |
1 1/4" | 25 | 68 | 82 | 110 |
1 1/2" | 32 | 80 | 97 | 140 |
2" | 40 | 91 | 119 | 140 |
2 1/2" | 50 | 114 | 148 | 250 |
3" | 57 | 124 | 160 | 250 |
4" | 68 | 132 | 177 | 250 |
Description | Raw Material | |
1 | Body | Brass |
2 | Seal Ring | PTFE |
3 | Ball | Brass |
4 | Stem | Brass |
5 | Packing Ring | PTFE |
6 | Lock Nut | Brass |
7 | Handle | Iron |
8 | Lock Nut | lron |
G | DN | L | H | A |
1/2" | 15 | 53 | 66 | 90 |
3/4" | 20 | 60 | 76 | 113 |
1" | 24 | 67 | 96 | 120 |
1 1/4" | 31 | 82 | 102 | 120 |
1 1/2" | 38 | 90 | 114 | 166 |
2" | 47 | 103 | 140 | 200 |
2 1/2" | 50 | 109 | 147 | 200 |
3" | 63 | 128 | 170 | 270 |
4" | 84 | 150 | 201 | 270 |
Description | Raw Material | |
1 | Body | Brass |
2 | Seal Ring | PTFE |
3 | Ball | Brass |
4 | Stem | Brass |
5 | Packing Ring | PTFE . |
7 | Lock Nut | Brass |
8 | Handle | lron |
G | DN | L | H | A |
1/2" | 15 | 62 | 66 | 90 |
3/4" | 20 | 70 | 76 | 113 |
1" | 24 | 77 | 96 | 120 |
Description | Raw Material | |
1 | Body | Brass |
2 | Seal Ring | PTFE |
3 | Ball | Brass |
4 | Stem | Brass |
5 | O-Ring | NBR |
6 | Packing Ring | PTFE |
7 | Handle | Aluminum |
8 | Lock Nut | lron |
G | DN | L | H | A |
1/2" | 15 | 62 | 70 | 90 |
3/4" | 20 | 66 | 83 | 116 |
1" | 25 | 82 | 91 | 116 |
1 1/4" | 32 | 89 | 105 | 149 |
1 1/2" | 40 | 105 | 116 | 149 |
2" | 50 | 118 | 139 | 185 |
2 1/2" | 62 | 125 | 163 | 230 |
3" | 69 | 150 | 180 | 230 |
4" | 84 | 160 | 205 | 254 |
Description | Raw Material | |
1 | Body | Brass |
2 | Ball | Brass |
3 | Stem | Brass |
4 | O-Ring | NBR |
5 | Lock Nut | lron |
6 | Handle | lron |
G | DN | L | H | A |
1/2" | 14 | 60 | 45 | 95 |
3/4" | 19 | 64 | 48 | 95 |
1" | 22 | 75 | 52 | 110 |
Description | Raw Material | |
1 | Body | Brass |
2 | Lock Nut | Brass |
3 | Pipe | Brass |
4 | Seal Ring | PTFE |
5 | Ball | Brass |
6 | Stem | Brass |
7 | O-Ring | NBR |
8 | Handle | Aluminum |
9 | Screw | Iron |
G | DN | L | H | A |
1/2" | 14 | 66 | 55 | 54 |
3/4" | 19 | 83 | 60 | 54 |
1" | 23 | 97 | 74 | 63 |
1 1/4" | 25 | 114 | 84 | 76 |
Description | Description | |
1 | Body | Body |
2 | Pipe | Pipe |
3 | L ock Nut | L ock Nut |
4 | Seal Ring | Seal Ring |
5 | Ball | Ball |
6 | Stem | Stem |
7 | O-Ring | O-Ring |
8 | Handle | Handle |
9 | Screw | Screw |
G | DN | L | H | A |
1/2" | 15 | 74 | 74 | 50 |
3/4" | 19 | 83 | 83 | 50 |
1" | 23 | 91 | 96 | 63 |
Description | Raw Material | |
1 | Body | Brass |
2 | Seal Ring | PTFE |
3 | Ball | Brass |
4 | Stem | Brass |
5 | 0-Ring | NBR |
6 | Handle | Aluminum |
7 | Lock Nut | Iron |
G | DN | L | H | A |
1/2" | 13.5 | 47 | 52 | 53 |
3/4" | 19 | 55 | 61 | 53 |
1" | 23 | 64 | 76 | 60 |
Description | Raw Material | |
1 | Body | Brass |
2 | Seal Ring | PTFE |
3 | Ball | Brass |
4 | Stem | Brass |
5 | 0-Ring | NBR |
6 | Handle | Aluminum |
7 | Lock Nut | Iron |
G | DN | L | H | A |
1/2" | 13.5 | 47 | 52 | 53 |
3/4" | 19 | 55 | 61 | 53 |
1" | 23 | 64 | 76 | 60 |
